3d aluminum composite panels
Shandong Golden Sunshine: Leading manufacturer of durable aluminum composite cladding panels. 20+ years experience, custom sizes, fire-resistant options. Competitive wholesale prices.
- 1-6mm
- 1100/3003/5005 Aluminum Alloy
- PE PVDF FEVE NANO
- Customer's Requirements
- 0.08/0.1/0.12/0.15/0.18/0.21/0.25/0.30/0.35/0.4/0.45/0.5mm
- Customized Size
3D Aluminum Composite Panels
Engineered Surface Technology
3D aluminum composite panels represent a technological advancement in architectural cladding, integrating precision-formed dimensional surfaces with high-performance composite construction. These panels undergo specialized hydraulic pressing and thermoforming processes to create permanent, consistent textures that maintain structural integrity while achieving complex geometric profiles.
Technical Advantages
The 3D aluminum composite panels deliver superior performance through advanced engineering:
| Advantage | Technical Benefit |
| Enhanced Durability | 30% higher impact resistance than flat panels |
| Structural Integrity | Maintains flatness with 0.3% maximum curvature |
| Thermal Performance | Improved insulation properties through air pockets |
| Acoustic Control | 25% better sound absorption than smooth surfaces |
| Maintenance Efficiency | Self-cleaning properties with hidden joint systems |
This innovative aluminum composite panel category offers both aesthetic and functional improvements over traditional flat panels. The dimensional characteristics of 3D aluminum composite panels provide inherent structural advantages while creating dynamic visual effects.
Technical Specifications
| Parameter | Performance Data |
|---|---|
| Surface Depth | 0.5mm to 3.0mm profile variations |
| Panel Thickness | 3mm to 6mm standard dimensions |
| Surface Hardness | ≥2H pencil hardness (PVDF coating) |
| Weight | 5.5-7.5 kg/m² depending on thickness |
| Fire Rating | A2-s1,d0 classification available |
The manufacturing process ensures uniform depth consistency across panel joints, maintaining visual continuity in large installations. This advanced aluminum composite panel technology allows for custom pattern development while meeting international building standards.
Architectural Applications
Curtain Wall Systems
Engineered for large-scale building envelopes where texture creates evolving visual effects through solar interaction. The dimensional surfaces reduce apparent scale while enhancing structural perception.
Interior Architectural Features
Specified for corporate environments, luxury retail spaces, and institutional buildings where tactile quality and acoustic performance are required alongside aesthetic considerations.
Custom Architectural Elements
Suitable for bespoke design applications including directional signage, feature ceilings, and integrated lighting systems that utilize the dimensional surface for functional purposes.
Technical Documentation
Comprehensive specification packages include material test reports, installation guidelines, and maintenance protocols.
Request technical portfolio with material samples and certification documents.
